34 - 36 GHz millimeter-wave RF Amplifier for high-frequency communication systems, satellite communications
Description
Here is a detailed introduction of the 34-36 GHz RF Amplifier:
-
Frequency Range: This RF amplifier operates within the frequency range of 34 GHz to 36 GHz, which falls into the millimeter-wave spectrum. These frequencies are commonly used in high-frequency communication systems, satellite communications, and radar applications.
-
Wideband Design: It features a wideband design, capable of effectively amplifying signals across the entire frequency range. This ensures versatility and stability in signal amplification.
-
Applications: The amplifier is suitable for various applications in the millimeter-wave frequency band, including but not limited to point-to-point communication systems, radar systems, satellite ground stations, and research in high-frequency technologies..
-
Stability and Reliability: The amplifier is engineered for stability and reliability, ensuring consistent performance over extended periods of operation and in challenging environmental conditions.
Overall, the 34-36 GHz RF Amplifier is designed to meet the amplification needs of signals within the millimeter-wave frequency band, offering wideband capabilities, stability, and reliability for a range of high-frequency applications.
Specification
Specifications subject to change without notice. Typical performance at +28VDC +25℃, and in a 50Ω system.
| ELECTRICAL SPECIFICATIONS@25℃ |
| PARAMETER | MIN | TYPICAL | MAX | UNIT |
| Frequency Range | 34 | | 36 | GHz |
| Gain | 16 | | | dB |
| Gain Flatness | | ±1 | | dB |
| Output Power | 33 | | | Watt |
| Spurious | | 60 | | dBc |
| Harmonics | | 20 | | dBc |
| VSWR | | | 2 | Ratio |
| Power Supply | | +12 | | Volt |
| Current | | 3 | | A |
Note: output with isolator.
| ENVIRONMENTAL RATINGS |
| PARAMETER | MIN | TYPICAL | MAX | UNIT |
| Max Input power | | | | dBm |
| Operating Temperature | -20 | | +50 | ℃ |
| Non-operating Temperature | -40 | | +85 | ℃ |
| Relative humidity (non-condensing) | | 95 | | % |
| Altitude (MIL-STD-810F) | 10000 | | 30000 | feet |
| Shock / Vibration (MIL-STD-810F) | | Airbone | | |
| MECHANICAL SPECIFICATIONS |
| PARAMETER | VALUE | LIMITS | UNIT |
| Dimensions | 40*40*15 | Max | Millimeter |
| Weight | 0.1 | Max | Kg |
| RF Connectors Input | 2.92mm-F | | |
| RF Connectors output | 2.92mm-F | | |
| Impedance | 50 | | Ohms |
